| SKU / Product Info | Quantity |
105121002000
- Nominal Size: 1/2 inch
- Outside Diameter: 3.5 inches
- Bolt Circle Diameter: 2.38 inches
- Thickness: 0.38 inch
- Number of Bolt Holes: 4
- Hub Diameter: 1.19 inches
- Length Through Hub: 1.81 inc
|
|
105121003000
- Nominal Size: 3/4 inch
- Outside Diameter: 3.88 inches
- Bolt Circle Diameter: 2.75 inches
- Thickness: 0.44 inch
- Number of Bolt Holes: 4
- Hub Diameter: 1.5 inches
- Length Through Hub: 2.0 inch
|
|
105121010000
- Nominal Size: 1 inch
- Outside Diameter: 4.25 inches
- Bolt Circle Diameter: 3.12 inches
- Thickness: 0.5 inch
- Number of Bolt Holes: 4
- Hub Diameter: 1.94 inches
- Length Through Hub: 2.12 inche
|
|
105121011000
- Nominal Size: 1-1/4 inch
- Outside Diameter: 4.62 inches
- Bolt Circle Diameter: 3.5 inches
- Thickness: 0.56 inch
- Number of Bolt Holes: 4
- Hub Diameter: 2.31 inches
- Length Through Hub: 2.19 i
|
|
105121012000
- Nominal Size: 1-1/2 inch
- Outside Diameter: 5.0 inches
- Bolt Circle Diameter: 3.88 inches
- Thickness: 0.62 inch
- Number of Bolt Holes: 4
- Hub Diameter: 2.56 inches
- Length Through Hub: 2.38 i
|
|
105121020000
- Nominal Size: 2 inch
- Outside Diameter: 6.0 inches
- Bolt Circle Diameter: 4.75 inches
- Thickness: 0.69 inch
- Number of Bolt Holes: 4
- Hub Diameter: 3.06 inches
- Length Through Hub: 2.44 inche
|
|
105121022000
- Nominal Size: 2-1/2 inch
- Outside Diameter: 7.0 inches
- Bolt Circle Diameter: 5.5 inches
- Thickness: 0.81 inch
- Number of Bolt Holes: 4
- Hub Diameter: 3.56 inches
- Length Through Hub: 2.69 in
|
|
105121030000
- Nominal Size: 3 inch
- Outside Diameter: 7.5 inches
- Bolt Circle Diameter: 6.0 inches
- Thickness: 0.88 inch
- Number of Bolt Holes: 4
- Hub Diameter: 4.25 inches
- Length Through Hub: 2.69 inches
|
|
105121032000
- Nominal Size: 3-1/2 inch
- Outside Diameter: 8.5 inches
- Bolt Circle Diameter: 7.0 inches
- Thickness: 0.94 inch
- Number of Bolt Holes: 8
- Hub Diameter: 4.81 inches
- Length Through Hub: 2.75 in
|
|
105121040000
- Nominal Size: 4 inch
- Outside Diameter: 9.0 inches
- Bolt Circle Diameter: 7.5 inches
- Thickness: 0.88 inch
- Number of Bolt Holes: 8
- Hub Diameter: 5.31 inches
- Length Through Hub: 2.94 inches
|
|
105121050000
- Nominal Size: 5 inch
- Outside Diameter: 10.0 inches
- Bolt Circle Diameter: 8.5 inches
- Thickness: 0.88 inch
- Number of Bolt Holes: 8
- Hub Diameter: 6.44 inches
- Length Through Hub: 3.44 inche
|
|
105121060000
- Nominal Size: 6 inch
- Outside Diameter: 11.0 inches
- Bolt Circle Diameter: 9.5 inches
- Thickness: 0.94 inch
- Number of Bolt Holes: 8
- Hub Diameter: 7.56 inches
- Length Through Hub: 3.44 inche
|
|
105121080000
- Nominal Size: 8 inch
- Outside Diameter: 13.5 inches
- Bolt Circle Diameter: 11.75 inches
- Thickness: 1.06 inch
- Number of Bolt Holes: 8
- Hub Diameter: 9.69 inches
- Length Through Hub: 3.94 inc
|
|
105121100000
- Nominal Size: 10 inch
- Outside Diameter: 16.0 inches
- Bolt Circle Diameter: 14.25 inches
- Thickness: 1.12 inch
- Number of Bolt Holes: 12
- Hub Diameter: 12.0 inches
- Length Through Hub: 3.94 i
|
|
105121120000
- Nominal Size: 12 inch
- Outside Diameter: 19.0 inches
- Bolt Circle Diameter: 17.0 inches
- Thickness: 1.25 inch
- Number of Bolt Holes: 12
- Hub Diameter: 14.38 inches
- Length Through Hub: 4.44 i
|
|
105121140000
- Nominal Size: 14 inch
- Outside Diameter: 21.0 inches
- Bolt Circle Diameter: 18.75 inches
- Thickness: 1.31 inch
- Number of Bolt Holes: 12
- Hub Diameter: 15.75 inches
- Length Through Hub: 4.94
|
|
105121160000
- Nominal Size: 16 inch
- Outside Diameter: 23.5 inches
- Bolt Circle Diameter: 21.25 inches
- Thickness: 1.38 inch
- Number of Bolt Holes: 16
- Hub Diameter: 18.0 inches
- Length Through Hub: 4.94 i
|
|
105121180000
- Nominal Size: 18 inch
- Outside Diameter: 25.0 inches
- Bolt Circle Diameter: 22.75 inches
- Thickness: 1.5 inch
- Number of Bolt Holes: 16
- Hub Diameter: 18.0 inches
- Length Through Hub: 5.44 in
|
|
105121200000
- Nominal Size: 20 inch
- Outside Diameter: 27.5 inches
- Bolt Circle Diameter: 25.0 inches
- Thickness: 1.62 inch
- Number of Bolt Holes: 20
- Hub Diameter: 22.0 inches
- Length Through Hub: 5.62 in
|
|
105121240000
- Nominal Size: 24 inch
- Outside Diameter: 32.0 inches
- Bolt Circle Diameter: 29.5 inches
- Thickness: 1.81 inch
- Number of Bolt Holes: 20
- Hub Diameter: 26.12 inches
- Length Through Hub: 5.94 i
|
|
