SKU / Product InfoQuantity
234053003002
  • Nominal Size: 3/4 x 1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 0.742 in ID x 1.05 in OD x 0.154 in THK, Branch: 0.546 in ID x 0.84 in OD x 0.147 in THK
234053010002
  • Nominal Size: 1 x 1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 0.957 in ID x 1.32 in OD x 0.179 in THK, Branch: 0.546 in ID x 0.84 in OD x 0.147 in THK
234053010003
  • Nominal Size: 1 x 3/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 0.957 in ID x 1.32 in OD x 0.179 in THK, Branch: 0.742 in ID x 1.05 in OD x 0.154 in THK
234053011002
  • Nominal Size: 1-1/4 x 1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.278 in ID x 1.66 in OD x 0.191 in THK, Branch: 0.546 in ID x 0.84 in OD x 0.147 in THK
234053011003
  • Nominal Size: 1-1/4 x 3/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.278 in ID x 1.66 in OD x 0.191 in THK, Branch: 0.742 in ID x 1.05 in OD x 0.154 in THK
234053011010
  • Nominal Size: 1-1/4 x 1 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.278 in ID x 1.66 in OD x 0.191 in THK, Branch: 0.957 in ID x 1.32 in OD x 0.179 in THK
234053012002
  • Nominal Size: 1-1/2 x 1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.5 in ID x 1.9 in OD x 0.2 in THK, Branch: 0.546 in ID x 0.84 in OD x 0.147 in THK
234053012003
  • Nominal Size: 1-1/2 x 3/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.5 in ID x 1.9 in OD x 0.2 in THK, Branch: 0.742 in ID x 1.05 in OD x 0.154 in THK
234053012010
  • Nominal Size: 1-1/2 x 1 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.5 in ID x 1.9 in OD x 0.2 in THK, Branch: 0.957 in ID x 1.32 in OD x 0.179 in THK
234053012011
  • Nominal Size: 1-1/2 x 1-1/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.5 in ID x 1.9 in OD x 0.2 in THK, Branch: 1.278 in ID x 1.66 in OD x 0.191 in THK
234053020002
  • Size: 2 x 1/2 inch
234053020003
  • Nominal Size: 2 x 3/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.944 in ID x 2.38 in OD x 0.218 in THK, Branch: 0.742 in ID x 1.05 in OD x 0.154 in THK
234053020010
  • Nominal Size: 2 x 1 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.944 in ID x 2.38 in OD x 0.218 in THK, Branch: 0.957 in ID x 1.32 in OD x 0.179 in THK
234053020011
  • Nominal Size: 2 x 1-1/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.944 in ID x 2.38 in OD x 0.218 in THK, Branch: 1.278 in ID x 1.66 in OD x 0.191 in THK
234053020012
  • Nominal Size: 2 x 1-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 1.944 in ID x 2.38 in OD x 0.218 in THK, Branch: 1.5 in ID x 1.9 in OD x 0.2 in THK
234053022003
  • Size: 2-1/2 x 3/4 inch
234053022010
  • Nominal Size: 2-1/2 x 1 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.323 in ID x 2.88 in OD x 0.276 in THK, Branch: 0.957 in ID x 1.32 in OD x 0.179 in THK
234053022011
  • Nominal Size: 2-1/2 x 1-1/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.323 in ID x 2.88 in OD x 0.276 in THK, Branch: 1.278 in ID x 1.66 in OD x 0.191 in THK
234053022012
  • Nominal Size: 2-1/2 x 1-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.323 in ID x 2.88 in OD x 0.276 in THK, Branch: 1.5 in ID x 1.9 in OD x 0.2 in THK
234053022020
  • Nominal Size: 2-1/2 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.323 in ID x 2.88 in OD x 0.276 in THK, Branch: 1.944 in ID x 2.38 in OD x 0.218 in THK
234053030010
  • Nominal Size: 3 x 1 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.9 in ID x 3.5 in OD x 0.3 in THK, Branch: 0.957 in ID x 1.32 in OD x 0.179 in THK
234053030011
  • Nominal Size: 3 x 1-1/4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.9 in ID x 3.5 in OD x 0.3 in THK, Branch: 1.278 in ID x 1.66 in OD x 0.191 in THK
234053030012
  • Nominal Size: 3 x 1-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.9 in ID x 3.5 in OD x 0.3 in THK, Branch: 1.5 in ID x 1.9 in OD x 0.2 in THK
234053030020
  • Nominal Size: 3 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.9 in ID x 3.5 in OD x 0.3 in THK, Branch: 1.939 in ID x 2.38 in OD x 0.218 in THK
234053030022
  • Nominal Size: 3 x 2-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 2.9 in ID x 3.5 in OD x 0.3 in THK, Branch: 2.323 in ID x 2.88 in OD x 0.276 in THK
234053032011
  • Size: 3-1/2 x 1-1/4 inch
234053032012
  • Nominal Size: 3-1/2 x 1-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.364 in ID x 4.0 in OD x 0.318 in THK, Branch: 1.5 in ID x 1.9 in OD x 0.2 in THK
234053032020
  • Nominal Size: 3-1/2 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.364 in ID x 4.0 in OD x 0.318 in THK, Branch: 1.939 in ID x 2.38 in OD x 0.218 in THK
234053032022
  • Nominal Size: 3-1/2 x 2-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.364 in ID x 4.0 in OD x 0.318 in THK, Branch: 2.323 in ID x 2.88 in OD x 0.276 in THK
234053032030
  • Nominal Size: 3-1/2 x 3 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.364 in ID x 4.0 in OD x 0.318 in THK, Branch: 2.9 in ID x 3.5 in OD x 0.3 in THK
234053040010
  • Size: 4 x 1 inch
234053040011
  • Size: 4 x 1-1/4 inch
234053040012
  • Nominal Size: 4 x 1-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.826 in ID x 4.5 in OD x 0.337 in THK, Branch: 1.5 in ID x 1.9 in OD x 0.2 in THK
234053040020
  • Nominal Size: 4 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.826 in ID x 4.5 in OD x 0.337 in THK, Branch: 1.939 in ID x 2.38 in OD x 0.218 in THK
234053040022
  • Nominal Size: 4 x 2-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.826 in ID x 4.5 in OD x 0.337 in THK, Branch: 2.323 in ID x 2.88 in OD x 0.276 in THK
234053040030
  • Nominal Size: 4 x 3 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.826 in ID x 4.5 in OD x 0.337 in THK, Branch: 2.9 in ID x 3.5 in OD x 0.3 in THK
234053040032
  • Nominal Size: 4 x 3-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 3.826 in ID x 4.5 in OD x 0.337 in THK, Branch: 3.364 in ID x 4.0 in OD x 0.318 in THK
234053050020
  • Nominal Size: 5 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 4.813 in ID x 5.56 in OD x 0.375 in THK, Branch: 1.939 in ID x 2.38 in OD x 0.218 in THK
234053050022
  • Nominal Size: 5 x 2-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 4.813 in ID x 5.56 in OD x 0.375 in THK, Branch: 2.323 in ID x 2.88 in OD x 0.276 in THK
234053050030
  • Nominal Size: 5 x 3 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 4.813 in ID x 5.56 in OD x 0.375 in THK, Branch: 2.9 in ID x 3.5 in OD x 0.3 in THK
234053050032
  • Nominal Size: 5 x 3-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 4.813 in ID x 5.56 in OD x 0.375 in THK, Branch: 3.364 in ID x 4.0 in OD x 0.318 in THK
234053050040
  • Nominal Size: 5 x 4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 4.813 in ID x 5.56 in OD x 0.375 in THK, Branch: 3.826 in ID x 4.5 in OD x 0.337 in THK
234053060020
  • Nominal Size: 6 x 2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 1.939 in ID x 2.38 in OD x 0.218 in THK
234053060022
  • Nominal Size: 6 x 2-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 2.323 in ID x 2.88 in OD x 0.276 in THK
234053060030
  • Nominal Size: 6 x 3 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 2.9 in ID x 3.5 in OD x 0.3 in THK
234053060032
  • Nominal Size: 6 x 3-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 3.364 in ID x 4.0 in OD x 0.318 in THK
234053060040
  • Nominal Size: 6 x 4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 3.826 in ID x 4.5 in OD x 0.337 in THK
234053060050
  • Nominal Size: 6 x 5 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 5.761 in ID x 6.62 in OD x 0.432 in THK, Branch: 4.813 in ID x 5.56 in OD x 0.375 in THK
234053080030
  • Nominal Size: 8 x 3 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 7.625 in ID x 8.62 in OD x 0.5 in THK, Branch: 2.9 in ID x 3.5 in OD x 0.3 in THK
234053080032
  • Nominal Size: 8 x 3-1/2 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 7.625 in ID x 8.62 in OD x 0.5 in THK, Branch: 3.364 in ID x 4.0 in OD x 0.318 in THK
234053080040
  • Nominal Size: 8 x 4 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 7.625 in ID x 8.62 in OD x 0.5 in THK, Branch: 3.826 in ID x 4.5 in OD x 0.337 in THK
234053080050
  • Nominal Size: 8 x 5 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 7.625 in ID x 8.62 in OD x 0.5 in THK, Branch: 4.813 in ID x 5.56 in OD x 0.375 in THK
234053080060
  • Nominal Size: 8 x 6 inch
  • Pipe Schedule: 80
  • Dimensions: Run: 7.625 in ID x 8.62 in OD x 0.5 in THK, Branch: 5.761 in ID x 6.62 in OD x 0.432 in THK
234053100040
  • Nominal Size: 10 x 4 inch
  • Pipe Schedule: *
  • Dimensions: Run: 9.75 in ID x 10.75 in OD x 0.5 in THK, Branch: 3.826 in ID x 4.5 in OD x 0.337 in THK
234053100050
  • Nominal Size: 10 x 5 inch
  • Pipe Schedule: *
  • Dimensions: Run: 9.75 in ID x 10.75 in OD x 0.5 in THK, Branch: 4.813 in ID x 5.56 in OD x 0.375 in THK
234053100060
  • Nominal Size: 10 x 6 inch
  • Pipe Schedule: *
  • Dimensions: Run: 9.75 in ID x 10.75 in OD x 0.5 in THK, Branch: 5.761 in ID x 6.62 in OD x 0.432 in THK
234053100080
  • Nominal Size: 10 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 9.75 in ID x 10.75 in OD x 0.5 in THK, Branch: 7.62 in ID x 8.62 in OD x 0.5 in THK
234053120040
  • Nominal Size: 12 x 4 inch
  • Pipe Schedule: *
  • Dimensions: Run: 11.75 in ID x 12.75 in OD x 0.5 in THK, Branch: 3.826 in ID x 4.5 in OD x 0.337 in THK
234053120050
  • Nominal Size: 12 x 5 inch
  • Pipe Schedule: *
  • Dimensions: Run: 11.75 in ID x 12.75 in OD x 0.5 in THK, Branch: 4.813 in ID x 5.56 in OD x 0.375 in THK
234053120060
  • Nominal Size: 12 x 6 inch
  • Pipe Schedule: *
  • Dimensions: Run: 11.75 in ID x 12.75 in OD x 0.5 in THK, Branch: 5.761 in ID x 6.62 in OD x 0.432 in THK
234053120080
  • Nominal Size: 12 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 11.75 in ID x 12.75 in OD x 0.5 in THK, Branch: 7.625 in ID x 8.62 in OD x 0.5 in THK
234053120100
  • Nominal Size: 12 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 11.75 in ID x 12.75 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053140060
  • Nominal Size: 14 x 6 inch
  • Pipe Schedule: *
  • Dimensions: Run: 13.0 in ID x 14.0 in OD x 0.5 in THK, Branch: 5.761 in ID x 6.62 in OD x 0.432 in THK
234053140080
  • Nominal Size: 14 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 13.0 in ID x 14.0 in OD x 0.5 in THK, Branch: 7.625 in ID x 8.62 in OD x 0.5 in THK
234053140100
  • Nominal Size: 14 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 13.0 in ID x 14.0 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053140120
  • Nominal Size: 14 x 12 inch
  • Pipe Schedule: *
  • Dimensions: Run: 13.0 in ID x 14.0 in OD x 0.5 in THK, Branch: 11.75 in ID x 12.75 in OD x 0.5 in THK
234053160060
  • Nominal Size: 16 x 6 inch
  • Pipe Schedule: *
  • Dimensions: Run: 15.0 in ID x 16.0 in OD x 0.5 in THK, Branch: 5.761 in ID x 6.62 in OD x 0.432 in THK
234053160080
  • Nominal Size: 16 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 15.0 in ID x 16.0 in OD x 0.5 in THK, Branch: 7.625 in ID x 8.62 in OD x 0.5 in THK
234053160100
  • Nominal Size: 16 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 15.0 in ID x 16.0 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053160120
  • Nominal Size: 16 x 12 inch
  • Pipe Schedule: *
  • Dimensions: Run: 15.0 in ID x 16.0 in OD x 0.5 in THK, Branch: 11.75 in ID x 12.75 in OD x 0.5 in THK
234053160140
  • Nominal Size: 16 x 14 inch
  • Pipe Schedule: *
  • Dimensions: Run: 15.0 in ID x 16.0 in OD x 0.5 in THK, Branch: 13.0 in ID x 14.0 in OD x 0.5 in THK
234053180080
  • Nominal Size: 18 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 17.0 in ID x 18.0 in OD x 0.5 in THK, Branch: 7.625 in ID x 8.62 in OD x 0.5 in THK
234053180100
  • Nominal Size: 18 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 17.0 in ID x 18.0 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053180120
  • Nominal Size: 18 x 12 inch
  • Pipe Schedule: *
  • Dimensions: Run: 17.0 in ID x 18.0 in OD x 0.5 in THK, Branch: 11.75 in ID x 12.75 in OD x 0.5 in THK
234053180140
  • Nominal Size: 18 x 14 inch
  • Pipe Schedule: *
  • Dimensions: Run: 17.0 in ID x 18.0 in OD x 0.5 in THK, Branch: 13.0 in ID x 14.0 in OD x 0.5 in THK
234053180160
  • Nominal Size: 18 x 16 inch
  • Pipe Schedule: *
  • Dimensions: Run: 17.0 in ID x 18.0 in OD x 0.5 in THK, Branch: 15.0 in ID x 16.0 in OD x 0.5 in THK
234053200080
  • Nominal Size: 20 x 8 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 7.625 in ID x 8.62 in OD x 0.5 in THK
234053200100
  • Nominal Size: 20 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053200120
  • Nominal Size: 20 x 12 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 11.75 in ID x 12.75 in OD x 0.5 in THK
234053200140
  • Nominal Size: 20 x 14 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 13.0 in ID x 14.0 in OD x 0.5 in THK
234053200160
  • Nominal Size: 20 x 16 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 15.0 in ID x 16.0 in OD x 0.5 in THK
234053200180
  • Nominal Size: 20 x 18 inch
  • Pipe Schedule: *
  • Dimensions: Run: 19.0 in ID x 20.0 in OD x 0.5 in THK, Branch: 17.0 in ID x 18.0 in OD x 0.5 in THK
234053240100
  • Nominal Size: 24 x 10 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 9.75 in ID x 10.75 in OD x 0.5 in THK
234053240120
  • Nominal Size: 24 x 12 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 11.75 in ID x 12.75 in OD x 0.5 in THK
234053240140
  • Nominal Size: 24 x 14 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 13.0 in ID x 14.0 in OD x 0.5 in THK
234053240160
  • Nominal Size: 24 x 16 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 15.0 in ID x 16.0 in OD x 0.5 in THK
234053240180
  • Nominal Size: 24 x 18 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 17.0 in ID x 18.0 in OD x 0.5 in THK
234053240200
  • Nominal Size: 24 x 20 inch
  • Pipe Schedule: *
  • Dimensions: Run: 23.0 in ID x 24.0 in OD x 0.5 in THK, Branch: 19.0 in ID x 20.0 in OD x 0.5 in THK

Quick Overview

    • Weldbend’s XS Reducing Tees are heavy-duty, butt-weld fittings designed to branch a main pipe into a smaller one under high-pressure conditions. Made to ASTM A234 WPB and ASME B16.9 standards.
    • Ideal for: chemical, power, steam, oil & gas, and industrial systems where robust performance and tight transitions are critical.
    • Key Features:
    • Material: Carbon Steel (ASTM A234 WPB)
    • Type: Reducing Tee (run branches into smaller side branch)
    • End Style: Butt Weld
    • Schedule: XS (Extra Strong, equivalent to SCH 80/XH)
    • Standards: ANSI/ASME B16.9 & ASTM A234 WPB
Interested in this item or want more information?

Hours:

Phone: 800-877-3030

Email: rvoelp@tri-state-industrial.com

Can't find what you want? Give us a call and we can help you find it.

Additional Information

Manufacturer: Weldbend

Powered by 48ws.com
© Tri-State Industrial Solutions, Inc. | All Rights Reserved
