Quick Overview
Features and Applications :-
- Superior flexibility in -40°C to 105°C temperature extremes
- Outstanding abrasion, ozone, sunlight, chemical and oil resistance, and water resistance in harsh environments
- Safety yellow provides superior contrast for better visibility in high-traffic industrial settings
- Temporary power distribution equipment
- Portable lighting and sound systems
- Indoor and outdoor portable power
Interested in this item or want more information?
Hours:
Phone: 800-877-3030
Email: rvoelp@tri-state-industrial.com
Can't find what you want? Give us a call and we can help you find it.
Details
Industry Approvals :- - UL Standard 62
- CSA Standard C22.2 No. 49
- NEC Article 501.140 Class I Div. 2
- NEC Article 400
- Federal Spec JC580
- Passes CSA FT2 Flame Test
- MSHA
- EPA 40 CFR, Part 26, Subpart C, heavy metals per Table 1, TCLP method
| Part Number | AWG | No. Cond. | Stranding | Insulation Wall, Nom. | O.D., Nom. | Net Weight | Amps* | Nom. DCR ?/1M' | Color Code |
| Inches | mm | Inches | mm | LB./Kft. | kg/km |
| 822245 | 18 | 2 | 16/30 | 0.030 | 0.76 | 0.346 | 8.79 | 65 | 97 | 10 | 6.59 | Black, White |
Additional Information
Manufacturer: Coleman Cable - CCI
