SKU / Product InfoQuantity
94722
12/2
94742
14/2
94744
14/4
94762
16/2
94764
16/4

Quick Overview

    Features & Applications :-
    • 99.97% Oxygen Free Conductors
    • Sequential footage markings
    • 34g bare copper conductors
    • Excellent abrasion resistance
    • Very flexible jacket even in cold weather
    • Power limited circuit and communication cable
    • Communications & intercom/PA Systems, sound/audio
    • Wide range of sound reproductions without distortion
Interested in this item or want more information?

Hours:

Phone: 800-877-3030

Email: rvoelp@tri-state-industrial.com

Can't find what you want? Give us a call and we can help you find it.

Details


Construction Parameters

Electrical Properties :

Conductor 12 AWG Bare Copper
Stranding 7x24/34
Insulation Material Foam Polypropylene
Insulation Thickness 0.009'' Nom
Insulated Conductor Dimensions 0.123'' Nom.
Number of Conductors 2
Lay Length 4.00'' Nom.
Core Wrap None
Jacket Material PVC
Jacket Thickness 0.020'' Nom
Overall Cable Diameter 0.286'' Nom.
Approximate Cable Weight 57.8 Lbs/1M' Nom
Flame Rating UL 1581 Vertical Tray Flame Test
Temperature Rating -20°C to 75°C
Rated Voltage 300 V RMS Max
Capacitance Between Conductors @ 1 KHZ 19 pF/ft Nom.
Capacitance Between Conductors to Shield @ 1 KHz ----
DC Resistance per Conductor @ 20°C 1.54 Ohms/1M' Nom

Additional Information


Manufacturer: Coleman Cable - CCI
