Quick Overview
Features & Applications:-
- PVC with Sun Resistance jacket
- Sequential Footage Marketing
- Pressure-Extruded Jacket is more staple resistant than a tubed jacket.
- Power limited circuit and communication cable for non-riser applications.
- Remote Control, Signaling, Security Systems, Communications, Single Line Telephone, Intercom/P.A. Systems
Interested in this item or want more information?
Hours:
Phone: 800-877-3030
Email: rvoelp@tri-state-industrial.com
Can't find what you want? Give us a call and we can help you find it.
Details
Construction Parameters :-
Electrical Properties:-
| Conductor | 22 AWG Bare Copper |
| Stranding | Solid |
| Insulation Material | Foam Polypropylene |
| Insulation Thickness | 0.006'' Nom. |
| Insulated Conductor Diameter | 0.032'' Nom. |
| Number of Conductors | 4 |
| Lay Length | Parallel |
| Jacket Material | PVC |
| Jacket Thickness | 0.014'' Nom. |
| Overall Cable Diameter | 0.106'' Nom |
| Approximate Cable Weight | 11.0 Lbs/1M' Nom. |
| Flame Rating | UL 1581 Vertical Tray Flame Test |
| Temperature Rating | -20°C to 75°C |
| Operating Voltage | 300 V RMS Max. |
| Capacitance Between Conductors @ 1 KHz | 18 pF/ft Nom. |
| Capacitance Between Conductors to Shield @ 1 KHz | ----- |
| Inductance | 0.09 uH/ft Nom |
| DC Resistance per Conductor @ 20°C | 26.42 Ohms/1M' Nom. |
Additional Information
Manufacturer: Coleman Cable - CCI
