Coleman Cables Rg59 20Bc 95 Bc Direct Burial (Flooded) Non-Ul

192115

Coleman Cable - CCI

Rg59 20Bc 95 Bc Direct Burial (Flooded) Non-Ul

Quick Overview

    Features & Applications:-
  • RG59 Type
  • PE Dielectric
  • PVC Jacket
    • Interested in this item or want more information?

    Hours:

    Phone: 800-877-3030

    Email: rvoelp@tri-state-industrial.com

    Can't find what you want? Give us a call and we can help you find it.

    Details

    Construction Parameters

    Electrical Properties

    Wall (in)* OD (in)*
    Conductors 20 AWG (1/.032) Solid Bare Copper - 0.032
    Dielectric Foam Polyethylene color natural0.0570.146
    Shielding95% Solid Bare Copper Braid -0.174
    WaterblockFlooding Compound --
    JacketPVC0.0340.242
    VALUE*
    Impedance (ohms)- 75
    Capacitance (Max. pF/ft) - 17
    Velocity of Propagation (%) - 78
    Attenuation (Max. db/100 ft) 50 MHz1.8
    100 MHz2.5
    200 MHz3.4
    400 MHz5.4
    700 MHz6.9
    1000 MHz8.2

    Additional Information

    Manufacturer: Coleman Cable - CCI
