Features& Application:-
- Manufactured in accordance with, tested & certified to individual Slant Sheets ie:(M17/028-RG058)
- RoHS & REACH compliant insulating compounds
- Test Reports with manufacturing lot for each & every cable
- Certificate of Compliance with MIL-DTL-17
- Made in the USA
- High frequency RF antenna for ground support equipment
- Radar systems & flight guidance equipment
- Secure & cryptic aerospace communications
Interested in this item or want more information?
Hours:
Phone: 800-877-3030
Email: rvoelp@tri-state-industrial.com
Can't find what you want? Give us a call and we can help you find it.
Details
Construction Parameters
Electrical Properties
|
| | OD (in)* |
Conductor | 22 AWG 0.0253” solid Copper clad steel | 0.025 |
Dielectric | Semi-Solid Polyethylene color natural (includes 0.035” Diameter
Monofilament thread (Air space) | 0.146 |
Shielding | 94% Bare Copper Braid | 0.172 |
Jacket | PVC (Non-Contaminating Vinyl Type IIA) | 0.242 |
| VALUE* |
Conductor Resistance (Max./100 ft) | 4.4 |
Shield Resistance (ohms/1000 ft | 2.9 |
Impedance (ohms) | 93 |
Capacitance (Max. pF/ft) | 14.5 |
Velocity of Propagation (%) | 84 |
Attenuation (Max. db/100 ft) |
100 MHz | 2.7 |
200 MHz | 41 |
400 MHz | 8.0 |
1000MHz | 13.0 |
Additional Information
Manufacturer: Coleman Cable - CCI
