Quick Overview
- 1/2” NPT inlet
- Through-hole socket retainer
- Built-in power regulator
- Pressure-feed mechanism lubrication
- Durable epoxy-coated handle/housing
- Integral muffler
- Jumbo Hammer mechanism
- Steel hammer case
Interested in this item or want more information?
Hours:
Phone: 800-877-3030
Email: rvoelp@tri-state-industrial.com
Can't find what you want? Give us a call and we can help you find it.
Details
| Model | 1720B3 | 1720P3 | 1712B2 | 1712P2 | 1734A1 |
|---|
| Description | 1" square | 1" square | 1" square | 1" square | No. 5 spline |
| Handle | Grip I.T. | Pistol | Grip I.T. | Pistol | Grip O.T. |
| Free Speed rpm | 5500 | 5500 | 6000 | 6000 | 6000 |
| Impacts per minute | 1000 | 1100 | 800 | 800 | 800 |
| Max Torque ft-lb (Nm) | 1,100 (1491) | 1,100 (1491) | 1,400 (1898) | 1,350 (1830) | 1,400 (1898) |
| Recomm. Torque Range ft-lb (Nm) | 250-750 (339-1017) | 250-750 (339-1017) | 450-1,000 (610-1356) | 450-1,000 (612-1860) | 450-1,000 (610-1356) |
| Weight Less Socket lb (kg) | 14 (6.35) | 3.19 (6.27) | 18.25 (8.28) | 18.25 (8.28) | 18.38 (8.34) |
| Length Less Socket in (mm) | 11.75 (299) | 7.63 (194) | 11.25 (286) | 11.25 (286) | 11.25 (286) |
| Side to Center Distance in (mm) | 1.91 (48) | 1.91 (48) | 2.19 (56) | 2.19 (56) | 2.19 (56) |
| Recommended Hose Size in (mm) | 1/2 (13) | 1/2 (13) | 3/4 (19) | 3/4 (19) | 3/4 (19) |
| CFM (L/min) | 40 (1132) | 40 (1132) | 47 (1331) | 56 (1585) | 47 (1331) |
Additional Information
Manufacturer: Ingersoll Rand
