G1-Series 0.40 hp (0.30 kW) Straight Grinders - Carbide Burr / Mounted Wheel

Ingersoll Rand

SKU / Product Info	Quantity
G1H200FG4 See Table Below
G1H200RG4 See Table Below
G1H250FG4 See Table Below
G1H250RG4 See Table Below
G1H350FG4 See Table Below
G1H350RG4 See Table Below

Quick Overview

The G1 Series Die Grinders feature a vane motor and a lightweight, composite housing that can stand up to harsh temperature changes. Compatible with piped-away exhaust kits, this powerful tool allows you to switch between front, rear and dual exhaust options.

Interested in this item or want more information?

Hours: 9:00AM -5:00 PM Mon-Fri

Phone: 800-877-3030

Email: rvoelp@tri-state-industrial.com

Can't find what you want? Give us a call and we can help you find it.

Details

Model	G1H200FG4	G1H200RG4	G1H250FG4	G1H250RG4	G1H350FG4	G1H350RG4
Rated Power hp (kW)	0.4 (0.3)	0.4 (0.3)	0.4 (0.3)	0.4 (0.3)	0.4 (0.3)	0.4 (0.3)
Max Free Speed (rpm)	20000	20000	25000	25000	35000	35000
Exhaust	Front	Rear	Front	Rear	Front	Rear
Output	1/4" Collet	1/4" Collet	1/4" Collet	1/4" Collet	1/4" Collet	1/4" Collet
Wheel Size in. (mm)	N/A	N/A	N/A	N/A	N/A	N/A
Weight lbs. (kg)	0.9 (0.4)	0.9 (0.4)	0.9 (0.4)	0.9 (0.4)	0.9 (0.4)	0.9 (0.4)
Length in. (mm)	6.13" (155)	6.13" (155)	6.13" (155)	6.13" (155)	6.13" (155)	6.13" (155)
Vibration m/s2	2.9, uncertainty: 1.7	2.9, uncertainty: 1.7	2.5, uncertainty: 1.4	2.5, uncertainty: 1.4	< 2.5	< 2.5
Sound Pressure/Power dBA	82.1 / 93.1	82.3 / 93.3	82.6 / 93.6	82.9 / 93.9	85.0 / 96.0	84.2 / 95.2
Average Air Consumption cfm (L/min)	N/A
Air Consumption @ Load cfm (L/min)	19 (538)	19 (538)	20 (566)	20 (566)	25 (708)	25 (708)
Air Inlet Size NPT in.	1/4"	1/4"	1/4"	1/4"	1/4"	1/4"
Min Hose Size in. (mm)	3/8" (10)	3/8" (10)	3/8" (10)	3/8" (10)	3/8" (10)	3/8" (10)

Additional Information

Manufacturer: Ingersoll Rand
